Selection principle of strip cladding welding equipment
|
Model |
TIME: TFD 30-ESK-75 or Soudokay: SK 30-ESK-75 |
TIME: TFD 60-ESK-75 or Soudokay: SK 60-ESK-75 |
TIME: TFD 125-ESK-300 or Soudokay: SK 125-ESK-300 |
|
Strip width (mm) |
30 |
30、60 |
30、60、90、120 |
|
Minimum Dia.(mm) |
Longitudinal：Φ380 Circumferential：Φ450 |
Longitudinal：Φ450 Circumferential：Φ650 |
Longitudinal：Φ650 Circumferential：Φ800 |
|
Welding current (A) |
SAW：380~500 ESW：450~650 |
SAW：650~950 ESW：850~1250 |
SAW：650~950 ESW：850~1250 |
|
Arc voltage (V) |
SAW：27~32, ESW：22~25 |
||
|
Cladding linear speed (mm/min) |
SAW：100~120, ESW：110~130 |
||
|
Wire feeder |
TFD (TIME), NA-3SF (Lincoln), A6(Esab) |
||
